Articulations#

Articulations are the preferred way to simulate mechanisms made of jointed rigid bodies (robots, grippers, ragdolls). PhysX simulates them in reduced coordinates — the configuration is the root pose plus the joint angles rather than the world pose of each body — which gives zero joint error by design and handles large mass ratios between links well.

You turn jointed rigid bodies into an articulation by applying UsdPhysics.ArticulationRootAPI (provided the joints are supported and loops are resolved). A rigid body that is part of an articulation is called a link.

This page builds on Rigid Bodies and Joints. For stability tuning, refer to the Articulation Stability guide.

Tree Structure#

An articulation must form a tree of links and joints. The tree is defined solely by the joints’ body0/body1 relationships — the USD hierarchy has no effect on the articulation structure (only on parsing, see below), so you may organize prims however you like.

Articulation examples: a ragdoll and a robotic arm

Because the algorithm works in reduced coordinates, setting poses and velocities on non-root links is not supported and triggers a warning. Read link poses/velocities through the ARTICULATION_LINK_* tensor types instead.

Floating vs Fixed Base#

  • Floating-base: the root link (and the whole mechanism) can move freely in space — for example a ragdoll.

  • Fixed-base: the root link is fixed to the world frame — for example a robot arm bolted to the ground.

Articulation Root#

Where you apply ArticulationRootAPI determines the articulation:

  • Fixed-base: apply it to the fixed joint that connects the base to the world, or to an ancestor of that joint. The fixed joint’s frames are ignored; its purpose is to mark the root link.

  • Floating-base: apply it to the root rigid-body link, or to an ancestor of it.

When the root is applied to an ancestor rather than a joint/link directly, the simulator determines the topology automatically: if any joint to the world is found the articulation is fixed-base (rooted at the world-connected body), otherwise it is floating-base (rooted at the link with minimal eccentricity). With automatic determination you cannot know the root beforehand, so applying poses/velocities to the root is only feasible after parsing.

Fixed-base example#

from pxr import UsdGeom, UsdPhysics, Gf

# Two links joined by a revolute joint.
for path in ("/World/link0", "/World/link1"):
    prim = UsdGeom.Xform.Define(stage, path).GetPrim()
    UsdPhysics.RigidBodyAPI.Apply(prim)
    UsdPhysics.MassAPI.Apply(prim).CreateMassAttr(2.0)

revolute = UsdPhysics.RevoluteJoint.Define(stage, "/World/revoluteJoint")
revolute.CreateAxisAttr(UsdPhysics.Tokens.y)
revolute.CreateBody0Rel().AddTarget("/World/link0")
revolute.CreateBody1Rel().AddTarget("/World/link1")

# Fixed joint to the world, marked as the articulation root -> fixed-base.
fixed = UsdPhysics.FixedJoint.Define(stage, "/World/fixedJoint")
fixed.CreateBody0Rel().AddTarget("/World/link0")
UsdPhysics.ArticulationRootAPI.Apply(fixed.GetPrim())

For a floating-base articulation, apply ArticulationRootAPI directly to the root link instead; initial pose and velocity may be set on the root link only.

The links_chain_sample.usda scene used by Hello World and Tensor Bindings is a ready articulation to experiment with.

Joint State (Initial Position and Velocity)#

Each degree of freedom of an articulation joint has position and velocity. Author initial values with the codeless PhysicsJointStateAPI (multiple-apply, instance name = axis token). Without it, joints start at zero.

from pxr import Sdf

joint_prim.ApplyAPI("PhysicsJointStateAPI", "angular")
joint_prim.CreateAttribute("state:angular:physics:position", Sdf.ValueTypeNames.Float).Set(45.0)
joint_prim.CreateAttribute("state:angular:physics:velocity", Sdf.ValueTypeNames.Float).Set(180.0)

At runtime, read and write joint state in bulk through the ARTICULATION_DOF_POSITION / ARTICULATION_DOF_VELOCITY tensor types (and root state through ARTICULATION_ROOT_POSE / ARTICULATION_ROOT_VELOCITY) — the preferred path for RL and control workloads. See Tensor Bindings.

Articulation Joint Drive and Performance Envelope#

A drive (a PD controller, per axis) is added with UsdPhysics.DriveAPI exactly as for regular joints (refer to Joints). Articulation joints additionally support a performance envelope that models actuator limits, applied per axis with the codeless PhysxDrivePerformanceEnvelopeAPI. It requires DriveAPI on the same axis because it uses the drive’s maxForce:

from pxr import Sdf, UsdPhysics

drive = UsdPhysics.DriveAPI.Apply(joint_prim, UsdPhysics.Tokens.angular)
drive.CreateMaxForceAttr().Set(100.0)

joint_prim.ApplyAPI("PhysxDrivePerformanceEnvelopeAPI", "angular")
joint_prim.CreateAttribute("physxDrivePerformanceEnvelope:angular:maxActuatorVelocity", Sdf.ValueTypeNames.Float).Set(180.0)
joint_prim.CreateAttribute("physxDrivePerformanceEnvelope:angular:speedEffortGradient", Sdf.ValueTypeNames.Float).Set(2.0)
joint_prim.CreateAttribute("physxDrivePerformanceEnvelope:angular:velocityDependentResistance", Sdf.ValueTypeNames.Float).Set(0.5)

PhysX enforces two constraints that define a feasible operating region in the (joint velocity, drive effort) plane:

[ |driveEffort| \le maxEffort - velocityDependentResistance \cdot |jointVelocity| ] [ |jointVelocity| \le maxActuatorVelocity - speedEffortGradient \cdot |driveEffort| ]

where maxEffort is the drive’s maxForce. driveEffort is the sum of the PD controller output and any user-defined joint effort. These drive-model parameters are also exposed at runtime through the ARTICULATION_DOF_DRIVE_MODEL tensor type.

Distinguish maxActuatorVelocity (envelope; clamps drive effort) from maxJointVelocity on PhysxJointAxisAPI (below; clamps the joint velocity itself).

Articulation Joint Friction and Armature#

Per-axis friction, armature, and max joint velocity are set with the codeless PhysxJointAxisAPI (multiple-apply, instance name = axis token). The friction model combines Coulomb friction (staticFrictionEffort, dynamicFrictionEffort) with viscous friction (viscousFrictionCoefficient):

from pxr import Sdf

joint_prim.ApplyAPI("PhysxJointAxisAPI", "angular")
joint_prim.CreateAttribute("physxJointAxis:angular:staticFrictionEffort", Sdf.ValueTypeNames.Float).Set(5.0)
joint_prim.CreateAttribute("physxJointAxis:angular:dynamicFrictionEffort", Sdf.ValueTypeNames.Float).Set(3.0)
joint_prim.CreateAttribute("physxJointAxis:angular:viscousFrictionCoefficient", Sdf.ValueTypeNames.Float).Set(0.1)
joint_prim.CreateAttribute("physxJointAxis:angular:armature", Sdf.ValueTypeNames.Float).Set(0.01)
joint_prim.CreateAttribute("physxJointAxis:angular:maxJointVelocity", Sdf.ValueTypeNames.Float).Set(10.0)

  • Armature is an artificial inertia added to the joint-space inertia (as if from an actuator) and helps stabilize an articulation.

  • staticFrictionEffort must be >= dynamicFrictionEffort.

  • These parameters apply only to joints that are part of an articulation.

Armature, joint friction, stiffness/damping, and limits are all also available in bulk at runtime through the ARTICULATION_DOF_ARMATURE, ARTICULATION_DOF_FRICTION_PROPERTIES, ARTICULATION_DOF_STIFFNESS, ARTICULATION_DOF_DAMPING, and ARTICULATION_DOF_LIMIT tensor types.

Closed Loops#

Articulation joints alone cannot form a closed loop (e.g. A-B, B-C, and C-A). To close a loop, mark the loop-closing joint as excluded from the articulation so it is simulated as a regular joint:

Articulation closed loop

fixed_joint.CreateExcludeFromArticulationAttr(True)

Excluding a joint is also how you connect two articulations to each other (for example a swappable manipulator on an arm). Loops are harder for the solver — if you hit instability, lower the timestep and refer to the Articulation Stability guide.

Mimic Joints#

Mimic joints couple the positions of two degrees of freedom of the same articulation with a linear relationship, q_A + G * q_B + gamma = 0 (gear ratio G, offset gamma). They implement gear and rack-and-pinion behavior specialized for articulations, with native GPU acceleration (prefer them over the CPU-only meta joints). Mimic joints support only revolute joints with limits applied.

Apply the codeless PhysxMimicJointAPI (multiple-apply, instance name = axis) to the driven joint and target the reference joint. Mimic joints support compliance (a spring-damper through natural frequency and damping ratio) to avoid instability when a mimic constraint competes with a stiff drive or hard contact — for example a gripper finger passively actuated through a mimic joint. A useful tuning metric is the product of timestep and natural frequency: start near 1 and increase the natural frequency until motion is no longer sluggish, keeping the damping ratio at or slightly above 1.

Tendons#

Tendons create constraints within an articulation. There are two kinds:

  • Fixed tendons couple joint positions: the tendon length is a weighted sum (per-joint gear ratios) of coupled joint positions, driven toward a rest length with stiffness/damping, and optionally kept within a range by a limit stiffness. The referenced joints must follow the articulation topology. Author with the codeless PhysxTendonAxisRootAPI / PhysxTendonAxisAPI on the joints.

  • Spatial tendons create line-of-sight distance constraints between links (modeling cables, hydraulic actuators, or artificial muscles). A tendon is a chain of attachments — a root (carries the spring-damper parameters), any number of regular attachments (route the tendon, exert no force), and leaf attachments (enforce the distance constraint). Author with the codeless PhysxTendonAttachmentRootAPI / PhysxTendonAttachmentAPI / PhysxTendonAttachmentLeafAPI.

Tendon properties (stiffness, damping, limit stiffness, limits, rest length/offset) are exposed at runtime through the fixed- and spatial-tendon tensor types — refer to Tensor Bindings.

Dynamics Queries#

For control algorithms, ovphysx exposes read-only articulation dynamics through tensor bindings: the ARTICULATION_JACOBIAN, ARTICULATION_MASS_MATRIX, ARTICULATION_CORIOLIS_AND_CENTRIFUGAL_FORCE, ARTICULATION_GRAVITY_FORCE, and ARTICULATION_LINK_INCOMING_JOINT_FORCE tensor types (plus ARTICULATION_CENTROIDAL_MOMENTUM for floating-base articulations). See Tensor Bindings.

Limitations and Differences#

  • Each link has a single inbound joint; loops must be broken as above.

  • Not all USD joint types are supported (refer to the table in Joints).

  • Spherical articulation joints have pyramidal swing limits, not elliptical cones; distance limits (distance token) are unsupported.

  • An articulation joint supports a single linear DOF or up to three angular DOFs — consider this when using a D6 joint in an articulation.

  • Articulation joint limits are hard constraints (no PhysxLimitAPI stiffness/ damping/restitution unless the joint is excluded from the articulation).

  • The breakForce/breakTorque attributes are ignored; articulation joints cannot be removed at runtime, and cannot gain limits after the stage is attached (initialize with unreachable limits if you may need them later).

  • Articulation joints cannot be instanced.

  • For a one-to-one relationship between USD and PhysX joint parameters (limits, drive targets) when using the tensor API, set up articulations so their USD and PhysX topologies are identical.
